Serial Baud Rate T-Shirt
“⸮⸮⸮ = Wrong Baud.”
A nerdy electronics tee: the standard serial baud rates, their timing error on a 16 MHz ATmega328P, the receiver's tolerance, and what ⸮⸮⸮ in a serial monitor means.
from $27
Plus shipping, shown at checkout. US sales tax included where it applies.
Checkout is run by Fourthwall, who print the shirt to order, ship it and handle returns and sales tax. You’ll pay on shop.troniction.com.
On the shirt
What it teaches
- Serial has no clock wire, so both ends must agree on the baud rate. When they don't, bytes still arrive but decode as garbage.
- ⸮ marks a byte that isn't valid text. The Arduino IDE shows it from 1.8.2 in the 1.x line; IDE 2 shows � instead. The usual suspect is a baud mismatch.
- At 16 MHz the ATmega328P hits 9600, 19200 and 38400 within 0.2 %. On the standard Arduino core, 57600 and 115200 both run about 2.1 % off.
- An 8N1 receiver tolerates about +4.58 / −4.54 % in total, so keep each end within ±2 %.
- An HC-05 module answers AT commands at 38400 only if KEY is held high while it powers up.
